assembly and installation
Installing the control unit and power supply unit
7160-9001-560
01. December 2020
20 / 74
4. Mounting the assembly using supports
The housing is fitted with a mounting plate suitable for wall and pipe mounting.
7160-5979-040 7160-5979-050 7160-5979-060 7160-2187-010 7160-5979-070
- Mount the control unit on a wall near the PC.
- Observe distances/cable length!
5. Electrical connection (CAN-Bus / Ethernet)
For more information on this subject please see section on:
Section: "Electrical connection"
6. After assembly and wiring, secure the
front flap with a screw.
