Geeetech A10 User Manual

SHENZHEN GETECH TECHNOLOGY CO,.LTD
33
7.2 Filament Setting
Set the filament diameter and printing temperature in the tab of Filament settings. Here we use 1.75mm PLA.
Usually the temperature of the print head is 195-210
℃
, the hot bed is 60-70
℃
. Here we set them as 200
℃
and 65
℃
. If you use ABS filament, the recommended temperature of the print head is 230-240
℃
(for the
actual temperature please refer to the data from manufacture of filament) and 90-110
℃
for the hot bed.

Geeetech A10 Specifications

General

Build Volume	220 x 220 x 260 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Bed Temperature	100°C
Connectivity	SD card, USB
Print Technology	FDM (Fused Deposition Modeling)
Frame Material	Aluminum
Heated Bed	Yes
Display	LCD
Machine Dimensions	478 x 413 x 485 mm
Max Nozzle Temperature	250°C
Supported Materials	PLA, ABS
Power Supply	24V
