gefran ADV200 WA DC Series

ADV200 WA • Quick start up guide - Specification and installation 111
268 [10.55”]
682 [26.85”]
270 [10.63”]
682 [26.85”] 616 [24.25”]
612 [24.09”]
Figure 9.10.5: Size 4 dimensions (ADV200 WA-...-4)
268 [10.55”]
270 [10.63”]
616 [24.25”]
612 [24.09”]
Figure 9.10.6: Size 4 dimensions (ADV200 WA-...-4-DC)
