gefran ADV200 WA DC Series

112 ADV200 WA • Quick start up guide - Specification and installation
311 [12.24”]
748 [29.45”]
853 [33.58”]
767 [40.2”]
325 [12.8”]
730 [28.74”]
220 [8.66”]
279 [10.98”]
265 [10.43”]
Figure 9.10.7: Size 5 dimensions (ADV200 WA-...-4)
311 [12.24”]
190 [7.48”]
730.4 [28.76”]
748 [29.45”]
265 [10.43”]
746 [30.55”]
325 [12.80”]
45.5 [1.79”]
Figure 9.10.8: Size 5 dimensions (ADV200 WA-...-4-DC)
