gefran ADV200 WA DC Series

ADV200 WA • Quick start up guide - Specification and installation 115
485 [19.1]
1209.5 [47.6]
170.7
240.5
310.5
177.8177.8
420
31
93
155
837
[33.0]
1407 [55.4]
1636.5 [64.4]
9.25
13
6.5
332
416.5
(*)
(*) Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
(Optional
BARS KIT)
144
114
84
420
155
6262 626262
Quote senza protezioni vedere taglia 7
See Size 7 for dimensions without protections.
Figure 9.10.13: Sizes 500 ... 800 kW dimensions
