228 AGy -L
LCD Display DESCRIPTION LCD Selection Description
Def.
Min
Max
Unit
Variat.
IPA
PARAMETER PICK LIST
Code
[6] DI 5 The command comes from
DigInp5
[7] DI 6 The command comes from
DigInp6
[8] DI 7 The command comes from
DigInp7
[9] DI 8 The command comes from
DigInp8
[10] DI Exp 1 The command comes from ExpDI
1
[11] DI Exp 2 The command comes from ExpDI
2
[12] DI Exp 3 The command comes from ExpDI
3
[13] DI Exp 4 The command comes from ExpDI
4
[14] AND 1 The command comes from the
output of the block AND1
[15] AND 2 The command comes from the
output of the block AND2
[16] AND 3 The command comes from the
output of the block AND3
[17] OR 1 The command comes from the
output of the block OR1
[18] OR 2 The command comes from the
output of the block OR2
[19] OR 3 The command comes from the
output of the block OR3
[20] NOT 1 The command comes from the
output of the block NOT1
[21] NOT 2 The command comes from the
output of the block NOT2
[22] NOT 3 The command comes from the
output of the block NOT3
[23] NOT 4 The command comes from the
output of the block NOT4
[24] FrqSel match The command is coming from the
output of the block Freq Sel
match
[25] ShortFloorFl The command is the short floor
flag
I.001 Run Fwd src Source of the Run Forward command of LCW
As for I.000 3 0 25 101
I.002 Run Rev src Source of the Run Reverse command of LCW
As for I.000 4 0 25 102
I.003 Freq Sel 1 src Source of the Frequency Selector 1 of LCW
As for I.000 5 0 25 103
I.004 Freq Sel 2 src Source of the Frequency Selector 2 of LCW
As for I.000 6 0 25 104
I.005 Freq Sel 3 src Source of the Frequency Selector 3 of LCW
As for I.000 7 0 25 105
I.006 Freq Sel 4 src Source of the Frequency Selector 4 of LCW
As for I.000 0 0 25 106
I.007 Ramp Sel 1 src Source of the Ramp Selector 1 of LCW
As for I.000 25 0 25 107
I.008 Ramp Sel 2 src Source of the Ramp Selector 1 of LCW
As for I.000 0 0 25 108
I.009 Ext fault src Source of the External Fault command of LCW
As for I.000 8 0 25 109
I.010 Faul reset src Source of the Fault Reset command of LCW
As for I.000 9 0 25 110
I.011 Bak pwr act src Source of the Backup Power Supply Active command of LCW
As for I.000 0 0 25 111
I.012 Forced stop src Source of the Forced Stop command of LCW
0 0 25 185
I.100 Dig output 1 cfg Digital output 1 configuration
[0] Drive Ready 51 0 55 112
[1] Alarm state
[2] Not in alarm
[3] Motor run
[4] Motor stop
[5] REV rotation
[6] Steady state
[7] Ramping
[8] UV running
