LCD Display DESCRIPTION LCD Selection Description
Def.
Min
Max Unit
Variat.
IPA
PARAMETER PICK LIST
Code
P.501 Sw freq reduc en Enabling of switching frequency reduction
[0] Disable 0 0 1 483
[1] Enable
P.502 Min switch freq Minimum switching frequency
As for P.500 (*) 0 P.500 495
P.520 Overmod max lev Overmodulation level
0 0 100 % 1 484
P.540 Out Vlt auto adj Automatic adjustment of output voltage
1 0 1 485
P.560 Deadtime cmp lev Dead times compensation limit
(*) 0 255 486
P.561 Deadtime cmp slp Dead times compensation slope
(*) 0 255 487
P.580 Startup display IPA of the parameter to be displayed at power on
8 1 1999 488
P.600 Speed dsply fact Speed conversion constant for display
10.00 0.01 99.99 0.01 489
P.998 Param access lev Access level
2 1 3 499
P.999 Param prot code Parameters protection code
0 Protection disabledStopped motor: possibility to
write all parameters.
Running motor: some
parameters are writing protected
(IPA in bold)
0 0 3 490
1 Protection
enabled
(*) = only with
motor stopped
All parameters are writing
protected excepted:
- F000, F100..F116, multispeed
function parameters
- P999 Param prot code
- C000 Save parameter (*)
- C020 Alarm clear
- H500..H511, serial line
commands.
2 Protection
enabled
(*) = only with
motor stopped
All parameters are writing
protected excepted:
- P999 Param prot code
- C000 Save parameter (*)
- C020 Alarm clear
- H500..H511, serial line
commands.
3 Protection disabledStopped motor: possibility to
write all parameters.
Running motor: some
parameters are writing protected
(IPA in bold)
Possibility to execute Save
parameter also with running
motor.
A.000 PID mode PID mode
[0] Disable Null 0 0 6 1200
[1] Freq sum PID out in sum with ramp out ref
(Feed forward)
[2] Freq direct PID out not in sum with ramp out
ref (no Feed forward)
[3] Volt sum PID out in sum with voltage ref
from V/f curve (Feed forward)
[4] Volt direct PID out not in sum with voltage
ref from V/f curve (no Feed
forward)
[5] Stand alone PID function as generic control
(only with drive in RUN)
[6] St-Al always PID function as generic control
(any drive status)
A.001 PID ref sel PID reference selector
[0] Null Null 0 0 7 1201
[1] Analog inp 1 Analog input 1
APPLICATION
