GENERAL MACHINE OPERATION
Check the Telescopic Handler to be sure all systems
are in good operating condition. Perform the following
steps before starting the machine the first time each
day:
1. Check the engine oil, coolant, transmission oil and
hydraulic oil levels.
2. Make sure weekly lubrication has been done.
3. Visually inspect for leaks, broken or malfunction-
ing parts. Make sure all caps, covers and safety
shields are in place.
4. Check tires for cuts, bulges, nails, correct pressure,
loose wheel nuts, etc.
5. Inspect the work area. Be sure you know where
you will make load pickups, placements, lifts, and
turns. Look over the terrain of the jobsite for holes,
obstacles, slippery surfaces, and soft or deep mud.
6. Check clearances of ramps, doorways and
passageways. Check overhead clearances if you
will travel and place loads near power or telephone
lines.
If the machine is found to be in need of repair or in any
way unsafe, or contributes to an unsafe condition, the
matter must be reported immediately to the user’s des-
ignated authority. The machine should NOT be operat-
ed until it has been restored to a safe operating condi-
tion.
Operate the travel controls gradually and smoothly
when starting, stopping, turning and reversing direc-
tion.
Grade and Slope Precautions
The Telescopic Handler complies with industry stabil-
ity test requirements and is stable when properly oper-
ated. However, improper operation, faulty mainte-
nance, and poor housekeeping can contribute to a con-
dition of instability.
The amount of forward and rearward tilt to be used is
governed by the application. Although use of maxi-
mum rearward tilt is allowable under certain condi-
tions, such as traveling with the load fully lowered, the
stability of the machine, as determined by the industry
standard tests, does not encompass consideration for
excessive tilt at high elevations, or the handling of off-
center loads.
Only handle loads within the capacity limits of the
machine, and which are stable and safely arranged.
When attachments are used, extra care should be taken
in securing, manipulating, positioning and transporting
the load.
Grade Limits
NOTE: Grade limits are based on ANSI/ITSDF
standard B56.6-2005.
The telescopic handler meets or exceeds the safety
standard (ANSI/ITSDF B56.6) stability limits for
rough terrain forklifts. The stability tipping limits
cover specific, controlled test conditions, which are
extremes, and which are not intended to be achieved
during normal worksite operations. The following
specifications are provided only as information to the
operator, and must not be used as a guideline for oper-
ating the telescopic handler. For safe operation, always
follow the instructions and warnings provided in this
manual.
1. DO NOT place or retrieve loads on an up or down
slope or grade that exceeds 7% or 4°.
2. DO NOT travel up or down a grade or slope that
exceeds 22% or 12° while loaded.
3. DO NOT place or retrieve loads on a side hill with
a slope or grade that exceeds 12% or 7°.
Regardless of the terrain or position of the wheels,
the FRAME MUST BE LEVEL, as indicated by
the frame angle indicator on the ROPS/FOPS
crossmember.
WARNING
Exhaust fumes can kill. Ensure proper ventila-
tion when starting indoors or in enclosed
areas.
Use proper hand-holds, NOT the steering
wheel or control levers as handholds when
mounting and dismounting.
NEVER operate the machine with safety
guards or covers removed.
Over-inflated tires can explode and cause
injury or death. Tire repairs MUST be made
only by authorized personnel using proper
tools and equipment.
