Chapter 2
SPECIFICATIONS
Lifting Performance
Maximum lift capacity:
6000 lbs. (2721 kg)
Maximum lift height:
34’-3” (10.44 m)
Capacity at maximum lift height:
4000 lbs. (1820 kg)
Max. forward reach to load center:
23’-3” (7.09 m)
Capacity at maximum forward reach:
900 lbs. (408 kg)
Maximum below grade reach:
24” (610 mm)
Frame leveling:
10
o
left/10
o
right
General Dimensions
Based on standard machine equipped
with listed tires, 48” masonry carriage
and 48” pallet forks.
Recommended tire type:
15.00 x 19.5 12-ply
Inflate to 60 psi (415 kPa)
Overall length, less forks:
16’-0” (4.88 m)
Overall width:
7’-10” (2.39 m)
Overall height:
7’-9” (2.36 m)
Ground clearance: 14” (356 mm)
Wheel base: 9’-2” (2.8 m)
Outside turn radius: 12’-6” (3.81 m)
Machine weight:
15,100 lbs. (6855 kg)
Instrumentation
Gauges: Fuel level, hourmeter
and coolant temperature
Monitoring lights:
Engine oil pressure, alternator,
transmission oil temperature,
brake failure
Visual indicators:
Boom angle, frame angle
Steering System
Steer Valve: Fixed displacement rotary
Displacement/Rev: 17.9 cu. in. (293 cc)
System pressure: 2000 psi (138 bar)
Steer cylinders: 1 per axle
Steer mode valve:
3-position, 4-way solenoid with
dash-mounted switch actuation
Steer modes: 2-wheel, 4-wheel, crab
Braking System
Service brakes: Oil-immersed inboard
hydraulic wet-disc type; separate front
and rear systems;
Manual foot pedal actuation
Parking brake: Spring-applied, hydraulic-
release disc-type in front axle
Actuation is electric switch with engine
running, automatic with engine off.
Electrical System
Type: 12-volt, negative ground
Battery: 950 cold cranking amps
Circuit protection: Fuse panel
Backup alarm: 107 dB(A)
Horn: 111 dB(A)
Standard features:
Brake lights, rear backup light, neutral
start switch
Alternator: 75-amp
Service Capacities
Cooling System: 4.3 gallons (16.3 L)
50/50 mixture
Anti-freeze protection: -34
o
F (-31
o
C)
Pressure cap: 16 psi (110 kPa)
Fuel tank: 29 gals. (110 L)
Hydraulic reservoir and
system: 35 gals. (133 L)
Transmission and cooler: 24 qts. (22.7 L)
Axles:
Differentials: 9.6 qts. (9 L) ea.
Hubs: 0.6 qts. (0.5 L) ea.
Transmission
Type: Clark Powershift T12000
Speeds: 3 fwd / 3 rev
Torque converter:
Single-stage, dual-phase
Travel Speeds:
1st gear: 3.6 mph (5.8 km/h)
2nd gear: 7.9 mph (12.7 km/h)
3rd gear: 20.2 mph (32.5 km/h)
Axles (front and rear)
Type: Dana
Drive/steer, open differential, double
reduction planetary, full-time four-
wheel drive
Overall ratio: 15.4:1
Engine Options
Features:
Turbocharged In-line 4-cycle,
4-cylinder, direct-injection diesel fuel
system, in-line fuel filter w/water
trap, positive pressure lubrication,
liquid pressurized cooling system,
20” (508 mm) blower fan,
dry dual-element air cleaner,
spin-on oil filter.
Machines with s/n 21541 thru 21700:
John Deere 4045T Tier 3
276 cu. in. (4523 cc) displacement
84 hp (63 kW) @ 2400 rpm
Oil capacity: 15.5 qts. (14.7 L)
Machines beginning with s/n 21701:
John Deere 4045T Interim Tier 4
276 cu. in. (4523 cc) displacement
74 hp (55 kW) @ 2400 rpm
Oil capacity: 15.5 qts. (14.7 L)
Hydraulic System
Type: Open-center
Pump: Single-section gear type
Displacement / revolution:
2.7 cu. in. (44.3 cc)
Flow @ 2500 RPM:
29 gpm (110 L/min)
Main relief pressure:
3000 psi (207 bar)
Steer relief pressure:
2000 psi (138 bar)
Hydraulic filter:
In-tank return type, 10 micron
media, replaceable element.
Rated flow: 100 gpm (379 L/min)
Rated pressure: 100 psi (690 kPa)
By-pass pressure (full flow):
25 psi (172 kPa)
Hydraulic strainer:
In-tank suction, 149 micron media,
replaceable element.
Rated flow: 50 gpm (189 L/min)
By-pass pressure: 3 psi (21 kPa)
To Next Page
