GENERAL INFORMATION
Decal location information is provided to assist in the
proper selection and application of new decals, in the
event the original decals become damaged or the
machine is repainted.
For correct replacement of decals, compare the loca-
tion photographs to the machine before starting to
refinish the unit. Check off each required decal using
the illustration reference number to find the part num-
ber, description and quantity in the list. Refer to the
appropriate illustration for replacement locations.
If there is a decal on a part that is being replaced, be
sure that the decal is applied to the replacement part.
NOTE: Refer to the Safety chapter of this manual
for specific information provided on the various
safety decals.
NEW DECAL APPLICATION
Before applying the new decals, surfaces must be free
from dirt, dust, grease and other foreign material. To
apply a solid-formed decal, remove the smaller portion
of the decal backing paper and apply this part of the
exposed adhesive backing to the clean surface while
maintaining proper position and alignment. Slowly
peel off the other portion of the backing paper while
applying hand pressure to smooth out decal surface. To
apply a die-cut decal, first remove the backing paper.
Then, properly orient and position the decal onto the
clean mounting surface. After the decal is firmly
applied and smoothly pressed down, peel off the top
covering paper.
PAINT FINISH
Use this list to order paint for refinishing:
167788 4 (1-qt. Cans) Yellow
167789 6 (12-oz. Spray Cans) Yellow
167754 4 (1-qt. Cans) Gun-Metal Gray
167757 6 (12-oz. Spray Cans) Gun-Metal Gray
Decal Kits
104916 RS6-34 Telescopic Handler without PWP
104917 RS6-34 Telescopic Handler with PWP
NOTE: Decals may be purchased in kits or indi-
vidually.
Chapter 9
DECAL LOCATIONS
CAUTION
ALWAYS read and follow the safety precau-
tions and information shown on decals. If any
decals are damaged or unreadable, or if the
unit is repainted, the decals must be replaced.
If repainting, BE SURE that all decals that
apply to your machine are affixed in their
proper locations
