Gehl RS6-34 - Electrical Schematics

913323/CP0112 64 PRINTED IN U.S.A.
REI. DESCRIPTION PART NO.
NO.
01 DANGER - HANDS OUT L70305
02 WARNING - PINCH POINT L65927
03 GEHL, 6.75” 184069
04 HYDRAULIC OIL FILL 137632
05 WARNING - NO RIDERS L65932
06 Gehl 2.00” 102026
07 DANGER - PERSONNEL INJURY (units without PWP) L65928
08 QUICK-ATTACH UNLOCKED L66613
09 DIESEL FUEL 50301416
10 RS6-34, RH 104872
11 HOT SURFACE L65942
DECAL LOCATIONS - FRAME AND BOOM
8
10
11
2
5
1
3
6
2
7
2
9
4
