Generac Power Systems E User Manual

14 Generac
®
Power Systems, Inc.
Section 2 — Operation
E Option Control Panels
Output Function Name Description
Function ID
00 Output Disabled Output not in use
01 Common Alarm Active for all latched, non-latched and shutdown alarms
02 Low Oil Pressure Warning Active after hold off time
03 Oil Pressure Shutdown Active after hold off time, low oil pressure
04 High Coolant Temp. Warning Active after hold off time
05 Coolant Temp. Shutdown Active after hold off time, high coolant temperature
06 Low Coolant Temp. Alarm
07 High Oil Temp. Warning
08 Oil Temp. Shutdown High oil temperature
09 Low Battery Voltage Must be below set value for five minutes
10 High Battery Voltage
11 Overspeed Shutdown
12 Underspeed Alarm Active after hold off time
13 Over Voltage Alarm Active after hold off time
14 Under Voltage Alarm Active after hold off time
15 Over Frequency Alarm Active after hold off time
16 Under Frequency Alarm Active after hold off time
17 High Fuel Alarm Above the warning set-point
18 Low Fuel Alarm Below the warning set-point
19 Low Fuel & Shutdown Below the shutdown set-point
20 Failed to Start Alarm Overcrank
21 Coolant Level Alarm Low coolant level
22 RPM Sensor Failed Alarm Magnetic pickup failure
23 Start Inhibit Alarm Oil pressure was present at start request
24 Emergency Stop Alarm Emergency stop active
25 Oil Press. Sense Fault Sensor is either open or short circuit
26 Oil Temp. Sense Fault Sensor is either open or short circuit
27 Coolant Temp. Sense Fault Sensor is either open or short circuit
28 Analog Channel 1 High Input at user analog channel 1 is above programmed high set-point
29 Analog Channel 1 Low Input at user analog channel 1 is below programmed low set-point
30 Analog Channel 2 High Input at user analog channel 2 is above programmed high set-point
31 Analog Channel 2 Low Input at user analog channel 2 is below programmed low set-point
32 Digital Channel 1 Active User programmable digital input 1 is active
33 Digital Channel 2 Active User programmable digital input 2 is active
34 Digital Channel 3 Active User programmable digital input 3 is active
35 Digital Channel 4 Active User programmable digital input 4 is active
36 Digital Channel 5 Active User programmable digital input 5 is active
37 Digital Channel 6 Active User programmable digital input 6 is active
38 Digital Channel 7 Active User programmable digital input 7 is active
39 Digital Channel 8 Active User programmable digital input 8 is active
40 Generator in Auto Key switch in auto position
41 Generator in Manual Key switch in manual position
42 Generator Off Key switch in off position
43 Stopped Generator stopped
44 Shutdown Due to Alarm Generator shutdown
45 Stopped Ready to Run Generator ready to start
46 Running Generator running
47 Ready to Accept Load Generator has reached load accept voltage and frequency set-points, and
the warm-up timer has expired
48 All Alarms Active Generator running
OUTPUT FUNCTION TABLE
