Power Systems, Inc. 63
ITEM PART NO. QTY. DESCRIPTION
1 0D4650 1 "E" PANEL BOTTOM/BACK W/TCONN
2 0C3872 1 FR0NT E PANEL 400KW
3 0A6322 1 PANEL RIGHT SIDE E
4 0A6321 1 PANEL LEFT SIDE E
5 0A6323 1 CHASSIS AVR & E-GOV
6 0D4267D 1 HARNESS "E" CONTROL PNL WT CON
7 0A4087 1 MSTR CTRL BOX E-PNL
8 070060 1 AMMETER 0-800
0A6798A 1 AMMETER 0-1600
0A6798B 1 AMMETER 0-2000
9 070043 1 VOLTMETER 0-300V
070044 1 VOLTMETER 0-600V
082404 1 VOLTMETER 0-750V
10 0C1212C 1 FREQUENCY METER 120V 55-65HZ
0C1212B 1 FREQUENCY METER 277V 55-65HZ
0C1212A 1 FREQUENCY METER 346V 55-65HZ
070042A 1 FREQUENCY METER 240V 45-55HZ
11 074386 1 SWITCH SELECT VOLT/AMP 3PH
12 0D4654 1 CONN DEUTSCH PLUG 21 PIN
13 0D4655 1 CONN DEUTSCH RECEPT 21 PIN
14 0C3207 1 DECAL T STRIP 1 E PNL
15 0A6576 1 DECAL T STRIP 2 E PNL
16 0C3208 1 DECAL T STRIP 3 E PNL
17 0C3206 1 DECAL T STRIP 4 E PNL
18 0C4110 1 RELAY 24V 50A W/DIODE
19 061286 1 SOUNALERT BUZZER
20 0C8243 2 WASHER LOCK HDP DEUTSCH
21 0E2693A 1 SWITCH MUSHRM HEAD/ARROWS 40MM
22 0E2693C 3 CONTACT BLOCK D5-3 X 01 W/2 1417
23 091472 1 DUCT WIRING 1 X 1.5 6 FT (9.5”)
24 091472A 1 COVER WIRE DUCT 1 IN (9.5”)
25 0E3703 1 LIGHT PANEL WITH LUG
26 083288 1 LIGHT 28VDC .17A MIN BAYNT MNT
27 070082 1 BLOCKER LIGHT
28 032300 1 HOLDER FUSE
29 022676 1 FUSE 15A X AGC15
30 0D4167 1 CONTROLLER B-C#:DPG-2107 (DSL)
31 0A2275 1 DOOR-STOP RAM PANEL
32 0A1441B 1 COVER PLATE AVR
33 0C2688 1 DECAL TERM STRIP TB4
34 0A1441C 1 COVER PLATE E GOV
ITEM PART NO. QTY. DESCRIPTION
35 0A3394 1 DECAL ELEC GOVERNOR
36 030809 1 GROMMET 11/16 X 1/8 X 7/16
37 029333 1 TIE WRAP 7.4" X .19" NATL UL
38 074130 1 LUG DIS SN-PLG I-T 22-18 CU
39 036261 4 RIVET POP .125 X ..275 AL
40 040479 4 MOUNT VIBR 1.0 X 1.0 X 1/4-20
41 0A2273 1 HINGE RAM PANEL
42 036901 8 SCREW PPHM #6-32 X 3/8
43 022155 17 WASHER LOCK #6
44 022985 18 WASHER FLAT #6 ZINC
45 0C2428 16 SCREW PHTT #6-32 X 1/2 ZYC
46 022188 10 NUT HEX #6-32 STEEL
47 036918 8 SCREW PPHM #8-32 X 1/2
48 022264 8 WASHER LOCK M4
49 038150 8 WASHER FLAT #8 ZINC
50 022471 4 NUT HEX #8-32 STEEL
51 033120 1 SCREW HHC #10-32 X 3/8
52 033121 13 SCREW HHC #10-32 X 1/2
53 022152 16 WASHER LOCK #10
54 023897 16 WASHER FLAT #10 ZINC
55 022158 3 NUT HEX #10-32 STEEL
56 022287 4 SCREW HHC 1/4-20 X 3/4 G5
57 022097 4 WASHER LOCK M6-1/4
58 022473 4 WASHER FLAT 1/4-M6 ZINC
59 047246 4 FLAT WASHER SPECIAL
60 0C8237 1 CONN DTCH HDP24-21PN
61 0D4655 1 CONN DEUTSCH RECEPT 21 PIN
62 0C8241 3 PIN SIZE 12 DEUTSCH
63 0C8242 4 SOCKET SZ 12 DEUTSCH
64 0C8244 2 NUT HDP DEUTSCH
65 0C5144 1 5 CONN DEUTSCH PIN #16-18 BLKHD
66 0D4651 1 5 PIN SIZE 14-16 1060-14-0122
67 0C5137 1 CONN DEUTSCH RECEPT BK/FLN
68 0C5141 1 CONN DEUTSCH GASKET BLKHD
69 0C5142 1 CONN DEUTSCH RECEPT WDGE BLKHD
70 0C5145 1 CONN DEUTSCH PLUG BLKHD BLK
71 0C5148 1 CONN DEUTSCH WEDGE LOCK 12-WAY
72 0C5185 6 CONN DEUTSCH SOCKET #16-20 DTM
73 044213 1 RES 10R 5% 12W
74 025192 1 RECTIFIER MSC 2A 600V 1N5062
75 036904 4 SCREW PPHM #6-32 X 3/4
Section 6 — Exploded Views and Parts Lists
Control Panel (For Use With Marathon Alternator) – Drawing No. 0D4267B-H
For units manufactured with a watertight connector
Standard drawing. Please refer to the Owner’s Manual of the unit for specific details.
