ITEM PART NO. QTY. DESCRIPTION
1 0A6320 1 CONTROL PANEL BOTTOM
2 0A6324 1 CONTROL PANEL FRONT
3 0A6322 1 CONTROL PANEL RIGHT SIDE
4 0A6321 1 CONTROL PANEL LEFT SIDE
5 0A6323 1 CHASSIS AVR/E GOV.
6 0A6326 1 HARNESS E PNL. MAIN
7 SEE TABLE B 1 CIRCUIT BREAKER
8 044213 1 RESISTOR 10 OHM 12W
9 025192 1 DIODE 600V 2A
10 SEE TABLE A 1 RESISTOR 2
11 055444 1 HEAT SINK
12 030468 1 STEP WASHER - NYLON
13 049939 1 RECTIFIER
14 039271 1 90° CONNECTOR 3/4"
15 034616 1 STRAIGHT CONNECTOR 3/4"
16 0A3392-C 1 DECAL, TERMINAL STRIP
17 0A6576 1 DECAL, TERMINAL STRIP TB2
18 0A6577 1 DECAL, TERMINAL STRIP TB3
19 0C2688 1 DECAL, TERMINAL STRIP TB4
20 048850 1 TERMINAL BLOCK, 5 POS TB4
22 061286 1 AUDIBLE ALARM
23 055089 1 HOUSING SOCKET 15 - CKT
24 0E2693A 1 SWITCH MUSHRM HEAD/ARROWS
40MM
25 0E2693C 3 CONTACT BLOCK D5-3X01 W/2,1417
26 071361 1 POTENTIOMETER
27 050123 1 KNOB
28 055349 1 INSULATOR
29 0A4087 1 MASTER CONTROL BOX
30 070202 1 PANEL LIGHT
31 070082 1 LIGHT BLOCKER
32 032300 1 FUSE HOLDER
33 022676 1 FUSE 15-A
34 070045 1 AMMETER
35 070043 1 VOLT METER AC 0-300
070044 1 VOLT METER AC 0-600
36 070042 1 FREQUENCY METER 60 HZ
070042A 1 FREQUENCY METER 50 HZ
37 061945 1 VOLT/AMP SWITCH
38 SEE TABLE C 1 AVR ASSEMBLY
39 SEE TABLE C 1 OPTIONAL ELECTRICAL GOVERNOR
39A 098941A 1 HOUSING, CONNECTOR
39B 098942A 1 COVER, CONNECTOR HOUSING
ITEM PART NO. QTY. DESCRIPTION
40 0A2275 1 FRONT PANEL STAY
41 0A2400A 1 TRUNKING 180MM
42 0A1441B 1 COVER PLATE, AVR
43 0A3393 1 DECAL, AVR COVER
44 0A1441C 1 COVER PLATE, E-GOV
45 0A3394 1 DECAL, E-GOV COVER
46 030809 1 GROMMET 1/8-11/16
47 028739 2 TIE WRAP 4"
48 0A1661 8 POP RIVET
49 036901 3 #6-32 X 3/8" PPHMS
50 022155 9 #6/M3 LOCK WASHER
51 036918 4 #8-32 X 1/2" PPHMS
52 022264 4 #8/M4 LOCK WASHER
53 038150 8 #8/M4 FLAT WASHER
54 022471 4 #8-32 HEX NUT
55 033120 1 #10-32 X 3/8" HHMS
56 033121 16 #10-32 X 1/2" HHMS
58 033147 1 #10-32 X 1" HHMS
59 022152 17 #10/M5 LOCK WASHER
60 023897 17 #10/M5 FLAT WASHER
61 022158 4 #10-32 HEX NUT
62 074130 1 LUG, PIN 4MM 22/18
63 036261 4 POP RIVET
64 070370 2 MICA WASHER
65 023762 1 WASHER EXTERNAL SHAKE PROOF
66 022985 6 #6/M3 FLAT WASHER
67 040479 4 VIBRATION DAMPENER
68 022287 4 1/4-20 X 3/4" HHMS
69 022097 4 1/4/M6 LOCK WASHER
70 022473 4 1/4/M6 FLAT WASHER
71 047246 4 1/4 FLAT WASHER SPECIAL
72 0A2273 1 HINGE
73 036902 4 #6-32 X 1/2" PPHMS
74 022188 4 #6-32 HEX NUT
75 0C2428 20 #6-32 X 1/2" TAPTITE
76 024413 1 #10-32 X 1/2" TAPTITE
77 0C2720 1 #10-32 X 3/8" TAPTITE
* 0A5705 1 INTERNAL MODULE FUSE, 5A (NOT
SHOWN)
78 060164 1 SOCKET DPDT P& B
79 057335 1 TERMINAL STRIP
80 055911 2 TERMINAL STRIP
81 0C2212 4 SCREW TAPTITE PH M4-0.7X16 ZYC
Section 6 — Exploded Views and Parts Lists
Control Panel (For Use With Generac Alternator) – Drawing No. 0A6325-N
For units manufactured prior to the 2nd quarter of 2000.
Standard drawing. Please refer to the Owner’s Manual of the unit for specific details.
