Power Systems, Inc. 71
ITEM PART NO. QTY. DESCRIPTION
1 0C2616 1 E PANEL BOTTOM 400>
2 0C3872 1 FRONT E PANEL 400>
3 0A6322 1 PANEL RIGHT SIDE E
4 0A6321 1 PANEL LEFT SIDE E
5 0A6323 1 CHASSIS AVR & E-GOV
6 0C1377 1 HARNESS E-PANEL 400>
7 0A4087 1 MASTER CONTROL BOX E-PANEL
8 SEE NOTE 1 AMMETER
9 SEE NOTE 1 VOLT METER AC
10 SEE NOTE 1 FREQUENCY METER
11 074386 1 SWITCH SELECT VOLT/AMP 3PH
12 0A9234 1 GEDNEY CONN 1IN 90
13 034616 1 FITTING STRAIGHT 3/4
14 0C3207 1 DECAL T STRIP 1 E PNL
15 0A6576 1 DECAL T STRIP 2 E PNL
16 0C3208 1 DECAL T STRIP 3 E PNL
17 0C3206 1 DECAL T STRIP 4 E PNL
18 0C4110 1 RELAY 24V 50A W/DIODE
19 061286 1 SOUNALERT BUZZER
20 055089 1 CONN PLUG PNL 15P AMP M-N-L
21 0E2693A 1 SWITCH MUSHRM HEAD/ARROWS
40MM
22 0E2693C 3 CONTACT BLOCK D5-3 X 01 W/2 1417
23 091472 1 DUCT WIRING 1 X 1.5 6 FT (9.5")
24 091472A 1 COVER WIRE DUCT 1 IN (9.5")
25 083287 1 LIGHT HLDR CLR LNS W/O BULB
26 083288 1 LIGHT 28VDC .17A MIN BAYNT MNT
27 070082 1 BLOCKER LIGHT
28 032300 1 HOLDER FUSE
29 022676 1 FUSE 15A X AGC15
30 084752 1 CONTROLLER GOVERNOR
ELECTRONIC
ITEM PART NO. QTY. DESCRIPTION
31 0A2275 1 DOOR-STOP RAM PANEL
32 0A1441B 1 COVER PLATE, AVR
33 0C1127 1 DECAL AVR COVER
34 0A1441C 1 COVER PLATE EGOV
35 0C1126 1 DECAL ELEC GOVERNOR COVER
36 030809 1 GROMMET 11/16 X 1/8 X 7/16
37 029333 1 TIE WRAP UL 7.4" X .19" NATL
38 074130 1 LUG DIS SN-PLG I-T 22-18 CU
39 036261 4 RIVET POP .125 X .275 AL
40 040479 4 VIB MNT 1.0 X 1.0 X 1/4-20
41 0A2273 1 HINGE RAM PANEL
42 036901 4 SCREW PPHM #6-32 X 3/8
43 022155 18 WASHER LOCK #6
44 022985 12 WASHER FLAT #6 ZINC
45 0C2428 14 SCREW PHTT #6-32 X 1/2 ZYC
46 022188 1 NUT HEX #6-32 STEEL
47 036918 8 SCREW PPHM #8-32 X 1/2
48 022264 8 WASHER LOCK #8-M4
49 038150 8 WASHER FLAT #8 ZINC
50 022471 4 NUT HEX #8-32 STEEL
51 033120 1 SCREW HHC #10-32 X 3/8
52 033121 17 SCREW HHC #10-32 X 1/2
53 022152 20 WASHER LOCK #10
54 023897 20 WASHER FLAT #10 ZINC
55 022158 7 NUT HEX #10-32 STEEL
56 022287 4 SCREW HHC 1/4-20 X 3/4 G5
57 022097 4 WASHER LOCK M6-1/4
58 022473 4 WASHER FLAT 1/4-M6 ZINC
59 047246 4 FLAT WASHER SPECIAL
NOTE: CONTACT GENERAC SERVICE FOR CORRECT PART NUMBER
FOR YOUR UNIT.
Section 6 — Exploded Views and Parts Lists
Control Panel (For Use With Marathon Alternator) – Drawing No. 0C3879-B
For units manufactured prior to the 2nd quarter of 2000.
Standard drawing. Please refer to the Owner’s Manual of the unit for specific details.
