Generac
®
Power Systems, Inc. 73
ITEM PART NO. QTY. DESCRIPTION
1 0A6320 1 CONTROL PANEL BOTTOM
2 0A6324 1 CONTROL PANEL FRONT
3 0A6322 1 CONTROL PANEL RIGHT SIDE
4 0A6321 1 CONTROL PANEL LEFT SIDE
5 0E3550 1 CHASSIS, UNIVERSAL
6 0C8320 1 HARNESS E PNL. WAUK (W/FS)
7 SEE TABLE B 1 CIRCUIT BREAKER
8 044213 1 RESIST MISC 10RX12W
9 025192 1 RECTIFIER MSC 2A 600V 1N5062
10 SEE TABLE A 1 RESISTOR 2
11 055444 1 HEAT SINK
12 030468 1 WASHER STEP NYLON .20
13 049939 1 RECTIFIER MSC 12A 600V 1N1206R
14 039271 1 FITTING 90DEGREE 3/4
15 034616 1 FITTING STRAIGHT 3/4
16 0A3392 1 DECAL TERMINAL STRIP
17 0C8229 1 DECAL E PNL TS#2 (W/FS)
18 0A6577 1 DECAL TERMINAL STRIP TB3
19 0C2688 1 DECAL TERMINAL STRIP TB4
20 048850 REF. BLOCK TERM 20A 5 X 6 X 1100V
22 061286 1 AUDIBLE ALARM
23 055089 1 CONN ELEC AMP M-N-L 15PLUG PNL
24 0E2693A 1 SWITCH MUSHRM HEAD/ARROWS
40MM
25 0E2693C 3 CONTACT BLOCK D5-3 X 01 W/2 1417
26 071361 1 POTENTIOMETER PNL 5K +/-10%
2.25W
27 050123 1 KNOB PLASTIC .25 SHAFT
28 055349 1 INSULATOR
29 0A4087 1 MASTER CONTROL BOX
30 0C8481 REF. BULB-PANEL LIGHT-12V
0E3703 REF. LIGHT PANEL WITH LUG
083288 REF. LIGHT 28VDC .17A MIN BAYNT MNT
31 070082 1 LIGHT BLOCKER
32 032300 1 FUSE HOLDER
33 022676 1 FUSE 15A X AGC15
34 070054 1 AMMETER AC 0-50
070055 1 AMMETER AC 0-100
070056 1 AMMETER AC 0-150
070057 1 AMMETER AC 0-300
070058 1 AMMETER AC 0-400
070059 1 AMMETER AC 0-600
070060 1 AMMETER AC 0-800
075323 1 AMMETER AC 0-1000
075324 1 AMMETER AC 0-1600
075325 1 AMMETER AC 0-2000
35 070043 1 METER VOLT AC 0-300
070044 1 METER VOLT AC 0-600
36 070042 1 METER FREQUENCY 55-65HZ
070042A 1 METER FREQUENCY 240V 45-55HZ
ITEM PART NO. QTY. DESCRIPTION
37 061945 1 SWITCH 6A AMP/V SELECTOR
38 067680 1 ASSY VOLTAGE REGULATOR 60HZ
092952 1 ASSY VOLTAGE REGULATOR 50HZ
40 0A2275 1 DOOR-STOP RAM PANEL
41 0A2400A 1 TRUNKING 180MM
42 0A1441B 1 COVER PLATE AVR
43 0C1127 1 DECAL AVR COVER
44 0A1441C 1 COVER PLATE E-GOV
45 0A3394 1 DECAL E-GOV COVER
46 030809 1 GROMMET 11/16 X 1/8 X 7/16
47 028739 2 TIE WRAP 4" WHITE
48 0C2323 12 SCREW PHM SWAGE 6-32 X 5/8 Z/YC
49 036901 4 SCREW PPHM #6-32 X 3/8
50 022155 7 WASHER LOCK #6
51 036918 8 SCREW PPHM #8-32 X 1/2
52 022264 8 WASHER LOCK M4
53 038150 4 WASHER FLAT #8 ZINC
54 022471 4 NUT HEX #8-32 STEEL
55 033120 1 SCREW HHM 10-32 X 3/8
56 033121 13 SCREW HHM 10-32 X 1/2
58 0A2284 4 SCREW SWAGE 8-32 X 1/2 Z/YC
59 022152 14 WASHER LOCK #10
60 023897 15 WASHER FLAT #10 ZINC
61 022158 2 NUT HEX #10-32 STEEL
62 074130 1 LUG DIS SN-PLG I-T 22-18 CU
63 036261 4 RIVET POP .125 X .129-.133/#30
64 070370 2 WASHER MICA .203
65 023762 1 WASHER SHAKEPROOF EXT #10 STL
67 040479 4 MOUNT VIBR 1.0 X 1.0 X 1/4-20
68 022287 4 SCREW HHC 1/4-20 X 3/4 G5
69 022097 4 WASHER LOCK M6-1/4
70 022473 4 WASHER FLAT M6-1/4 ZINC
71 047246 4 WASHER FLAT 1/4 SPECIAL
72 0A2273 1 HINGE RAM PANEL
74 022188 2 NUT HEX #6-32 STEEL
75 0C2428 8 SCREW TAPTITE PH #6-32 X 1/2 ZYC
* 0A5705 1 FUSE 5A X LTTL215005 HLDRA4017
(NOT SHOWN)
78 057335 REF. BLOCK TERM 20A 20 X 6 X 1100V
79 0C4167 REF. BLOCK TERM 20A 14 X 6 X 1100V
80 055911 REF. BLOCK TERM 20A 12 X 6 X 1100V
81 0441140156 REF. WIRE ASSEMBLY
82 084717 1 ASSY TIME DELAY (13.3L GAS ONLY)
83 036908 1 SCREW PPHM #6-32 X 1-1/4 (13.3L
GAS ONLY)
84 0C1229 1 DECAL WARNING
85 0E3783 1 DECAL WARNING REMOVE FUSE
Section 6 — Exploded Views and Parts Lists
Control Panel (For Use With Generac Alternator) – Drawing No. 0C8459-J
For units manufactured starting the 2nd quarter of 2000 thru 3rd quarter 2002.
Standard drawing. Please refer to the Owner’s Manual of the unit for specific details.
