Generac Power Systems E User Manual

Generac
®
Power Systems, Inc. 75
ITEM PART NO. QTY. DESCRIPTION
1 0C2616 1 CONTROL PANEL BOTTOM
2 0C3872 1 CONTROL PANEL FRONT
3 0A6322 1 CONTROL PANEL RIGHT SIDE
4 0A6321 1 CONTROL PANEL LEFT SIDE
5 0E3550 1 CHASSIS, UNIVERSAL
6 0C8328 1 HARNESS E PANEL MAIN
7 0A4087 1 MASTER CONTROL BOX
8 SEE NOTE 1 AMMETER
9 SEE NOTE 1 VOLT METER AC
10 SEE NOTE 1 FREQUENCY METER
11 074386 1 SWITCH VOLT/AMP
12 0A9234 CONNECTOR 90 DEGREE ELBOW
13 034616 1 FITTING STRAIGHT 3/4
14 0C3207 1 DECAL TERM STRIP TB1
15 0C8229 1 DECAL TERM STRIP TB2
16 0C3208 1 DECAL TERM STRIP TB3
17 0C3206 1 DECAL TERM STRIP TB4
18 0C4110 1 RELAY 24V 50A W/DIODE
19 061286 1 ALARM AUDIBLE
20 055089 1 CONN ELEC AMP M-N-L 15PLUG PNL
21 098426A 1 SWITCH EMERGENCY STOP
22 098426C 3 CONTACT EMERGENCY STOP
SWITCH
23 091472 9.5" WIRE DUCT1 X 1.5
24 091472A 9.5" WIRE DUCT COVER 1"
25 0E3703 1 LIGHT PANEL WITH LUG
26 083288 1 LIGHT 28VDC .17A MIN BAYNT MNT
27 070082 1 LIGHT BLOCKER
28 032300 1 FUSE HOLDER
29 022676 1 FUSE 15A X AGC15
30 067710 1 CONTROLLER ELECTRONIC
GOVERNOR
31 0A2275 1 DOOR-STOP RAM PANEL
32 0A1441B 1 COVER PLATE AVR
33 0C1127 1 DECAL AVR COVER
34 0A1441C 1 COVER PLATE ELECTRONIC
GOVERNOR
ITEM PART NO. QTY. DESCRIPTION
35 0A3394 1 DECAL ELECTRONIC GOVERNOR
36 030809 1 GROMMET 11/16 X 1/8 X 7/16
37 029333 1 TIE WRAP 7" WHITE
38 074130 1 LUG DIS SN-PLG I-T 22-18 CU
39 036261 4 RIVET POP .125 X .129-.133/#30
40 040479 4 MOUNT VIBR 1.00 X 1.00 X 1/4-20
41 0A2273 1 HINGE RAM PANEL
42 036901 4 SCREW PPHM #6-32 X 3/8
43 022155 7 WASHER LOCK #6
45 0C2323 12 SCREW TAPTITE PH 6-32 X 5/8 ZYC
47 036918 4 SCREW PPHM #8-32 X 1/2
48 022264 8 WASHER LOCK M4
49 038150 4 WASHER FLAT M4
50 0A2284 4 SCREW SWAGE 8-32 X 1/2 Z/YC
51 033120 1 SCREW HHM 10-32 X 3/8
52 033121 17 SCREW HHM 10-32 X 1/2
53 022152 20 WASHER LOCK #10
54 023897 20 WASHER FLAT #10 ZINC
55 022158 6 NUT HEX #10-32 STEEL
56 022287 4 SCREW HHC 1/4-20 X 3/4 G5
57 022097 4 WASHER LOCK M6-1/4
58 022473 4 WASHER FLAT M6-1/4 ZINC
59 047246 4 WASHER FLAT 1/4 SPECIAL
60 057335 1 BLOCK TERM 20 POS TB1
61 0C4167 1 BLOCK TERM 20A 14 X 6 X 1100V
62 055911 1 BLOCK TERM 20A 12 X 6 X 1100V
63 061520 1 BLOCK TERM 20A 9 X 6 X 1100V
64 0441140156 1 WIRE ASSY 18AWG #0
65 022188 2 NUT HEX #6-32 STEEL
66 0C1229 1 DECAL WARNING
67 046669 17 BLOCK TERM JUMPER
68 0E3783 1 DECAL, WARNING REMOVE FUSE
NOTE: CONTACT GENERAC SERVICE FOR CORRECT PART NUMBER
FOR TOUR UNIT.
Section 6 — Exploded Views and Parts Lists
Control Panel (For Use With Marathon Alternator) – Drawing No. 0C8460-G
For units manufactured starting the 2nd quarter of 2000.
Standard drawing. Please refer to the Owner’s Manual of the unit for specific details.
