Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Control System
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 29
Screen or Menu Item Default
Turntable Ramps CW Accelerating 5000 ms max, 1000 ms min, 3000 ms (default)
CW Decelerating 5000 ms max, 500 ms min, 2000 ms (default)
CCW Accelerating 5000 ms max, 1000 ms min, 3000 ms (default)
CCW Decelerating 5000 ms max, 500 ms min, 2000 ms (default)
Screen or Menu
Item
Default
Jib Boom and
Platform Speeds
Jib Up Threshold max 120% / min 1% / default 550 mA
Jib Down Threshold max 123% / min 1% / default 506 mA = 100%
Platform Level Up Threshold max 130% / min 1% / default 433 mA = 100%
Platform Level Down
Threshold
max 121% / min 1% / default 446 mA =100%
Platform Rotate CW
Threshold
max 111% / min 1% / default 545 mA = 100%
Platform Rotate CCW
Threshold
max 113% / min 1% / default 561 mA = 100%
Jib Up Max Output max 150% / min 86% / default 776 mA = 100%
Jib Down Max Output max 150% / min 85% / default 741 mA = 100%
Platform Level Up Max Output max 150% / min 81% / default 700 mA = 100%
Platform Level Down Max
Output
max 150% / min 86% / default 637 mA = 100%
Platform Rotate CW Max
Output
max 150% / min 91% / default 671 mA = 100%
Platform Rotate CCW Max
Output
max 150% / min 90% / default 716 mA = 100%
Screen or Menu Item Default
Jib and Platform
Ramps
Jib Up/Down Ramp max 2000 ms / min 200 ms / default 750 ms
Platform Level Ramp max 2000 ms / min 200 ms / default 750 ms
Platform Rotate Ramp max 2000 ms / min 200 ms / default 600 ms
Screen or Menu Item Default
Machine Disable
Options
Drive Disable On / Off
Machine Disable On / Off
Remote Disable
Disable Engine Start / Drive Speed Cripple / Lift Speed Cripple
Reset to Defaults OK to reset Model Configuration and Options
Software Update OK to enter Software Update Mode
