Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Control System
28 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Screen or Menu Item Default
Primary Lift Speeds Extend Thresholds 140% max, 1% min, 100% = 483 mA (default)
Retract Threshold 150% max, 1% min, 100% = 441 mA (default)
Up Threshold 147% max, 1% min, 100% = 846 mA(default)
Down Threshold 149% max, 1% min, 100% = 861 mA (default)
Extend Max 150% max, 78% min, 100% = 877 mA (default)
Retract Max 150% max, 75% min, 100% = 889 mA (default)
Up Max 150% max, 76% min, 100% = 1657 mA (default)
Down Max 150% max, 76% min, 100% = 1720 mA (default)
Screen or Menu Item Default
Primary Lift Ramps Extend Accelerating Rate 5000 ms max, 1000 ms min, 2500 ms (default)
Extend Decelerating Rate 5000 ms max, 250 ms min, 1000 ms (default)
Retract Accelerating Rate 5000 ms max, 1000 ms min, 2500 ms (default)
Retract Decelerating Rate 5000 ms max, 500 ms min, 1000 ms (default)
Up Accelerating Rate 5000 ms max, 1000 ms min, 3000 ms (default)
Up Decelerating Rate 5000 ms max, 500 ms min, 3000 ms (default)
Down Accelerating Rate 5000 ms max, 1000 ms min, 3000 ms (default)
Down Decelerating Rate 5000 ms max, 1000 ms min, 1000 ms (default)
Screen or Menu Item Default
Turntable Speeds Rotate CW Max 150% max, 75% min, 100% = 1150 mA (default)
Rotate CCW Max 150% max, 75% min, 100% = 1150 mA (default)
Rotate CW Threshold 139% max, 1% min, 100% = 560 mA (default)
Rotate CCW Threshold 139% max, 1% min, 100% = 560 mA (default)
CW Out of Stow Max 150% max, 78% min, 100% = 1005 mA (default)
CCW Out of Stow Max 150% max, 78% min, 100% = 1005 mA (default)
