2.2.4
DISTANCE MEASUREMENT SYSTEM CHAPTER 2
GEODIMETER SYSTEM 600
This measurement mode is normally used during control
surveys – e.g., traversing, minor tacheometric exercises,
survey point accuracy control, etc. Measurement time to each
point takes 3.5 seconds. This measurement mode is also
normally used where a normal degree of angle and distance
accuracy is required.
The instrument carries out the measurement and display of
horizontal and vertical angles and slope distances. Horizon-
tal distance and difference in height, and the northings,
eastings and elevation of the point will all be displayed by
pressing the ENT key twice. Collimation and horizontal axis
tilt errors are compensated and full angle accuracy can be
achieved with one-face measurements. The instrument also
offers the possibility of using the R.O.E. function in the STD-
measurement mode (see page 2.2.10). Limited horizontal
movement of the instrument telescope, i.e. within 30 cm, will
also result in the northings and eastings of the measured
point changing. This feature is used when measuring of
eccentric objects (see page 2.2.7.).
This measurement mode is used when the object is stationary
but the demands on precision are low. The measurement
time is very short, approx. 1.3 seconds.
The measurement is performed in the same way as the
standard measurement.
Switch between Fast Standard and Standard Measurement Mode
You can configure the STD-key to work in Standard- or Fast
Standard mode in menu 62.
STD
Standard measurement (STD Mode)
Fast standard measurement (STD mode)
STD
MNU
6
2
