1.1.9
INTRODUCTION CHAPTER 1
GEODIMETER SYSTEM 600
The System 600 features two different control units; a
numeric and an alphanumeric one.
The alphanumeric control unit simplifies the entering of
point codes and basic editing by having all alpha characters
on separate keys. You can, however, also enter alpha char-
acters with the numeric control unit, but this needs extra key
presses.
The control units are ergonomically and logically designed.
The alphanumeric control unit consists of 33 keys: the
numerals 0-9, letters A-Z, and control keys. The control
keys comprise the choice of functions 0-126, choice of
menu, choice of program and choice of measurement mode,
together with clear and enter functions etc.
The numeric control unit consists of 22 keys, see fig 1.6.
But the control unit unit is more than just a keyboard, it also
contains the internal memory as well as any of the softwares
that are available.
Detachable control unit
The control unit is detachable and this makes it very easy for
the user to transfer data. Simply detach the control unit after
a survey and bring it to the office (it's very handy and fits in
a normal size pocket). Attach the control unit to a computer
using the multifunctional cable. Run Program 54 or Geotool
to transfer data between the units.
Note!
The control unit should not be attached/detached when the
instrument is switched on.
Assigned control units
In a surveying team each member can have his/her own
control unit with his/her own setups, softwares and internal
memory. This means that any operator can attach his/her
assigned control unit to any Geodimeter System 600 and get
it to work with his/her specific U.D.S's and setups.
The Control unit
Note!
☛
