2.5.4
TRACKER CHAPTER 5
GEODIMETER SYSTEM 600
Lock on target
When the instrument is locked on the RMT this is indicated
by a + on the display. When moving the RMT, still visible
for the instrument, the instrument will automatically follow.
If loosing contact with the instrument in STD-, FSTD or D-mode
If the instrument loose visible contact with the RMT, Info
161 (Target lost) will be displayed. Aim the RMT towards
the instrument and press the A/M-key to start searching
(optional) or use the servo controls to regain contact. The
function "Advanced lock" can also be used in these
measurement modes (see page 2.5.6 for further explanation).
If loosing contact with the instrument in TRK-mode
If the instrument loose visible contact with the RMT, Info
161 (Target lost) will be displayed. Use the servo controls to
regain contact.
With the search option:
The tracker can be set to automatically start to seek for the
RMT in the search window. The instrument searches
through the whole search window, both horizontally and
vertically. If the target isn't found the text
"Target lost"
appears. Press the A/M-key (optional) or use the servo
controls to regain contact if you have changed the position
much. The function "Advanced lock" can also be used in this
measurement mode (see page 2.2.6).
To speed up the search routine, you can set a "window" in
which the instrument should seek for the target. When
setting up the instrument for remote or robotic surveying you
automatically will be prompted to set a search window, but
when performing conventional surveying with Autolock™,
you must enter the RPU menu and choose Window control
to do the same.
Controlling the tracker (OPTIONAL for Autolock™)
