2.8.3
POWER SUPPLY CHAPTER 8 GEODIMETER SYSTEM 600
Battery Cables
The multifunctional cable is required if an external battery is
used or when connecting the different Spectra Precision devices
with each other. The different types of cables are listed below:
Multifunctional Cable 1m, 571 202 188,
for connecting the
Geodimeter instrument or control unit to an external battery
via the Single or Multi Adapter or to another control unit or
instrument. Length: 1.0m.
Multifunctional Cable 2.5m, 571 202 216,
same as the above
cable. Length: 2.5m.
Multifunctional Cable 0.4m, 571 208 043,
same as the above
cable. Length: 0.4m.
Data Communication Adapter, 571 202 204,
for connecting the
Geodimeter instrument or control unit to a computer and a
Power Supply or an external battery using the Single or
Multi Adapter.
Single Adapter
The Single Adapter (Part No. 571 204 256) is used when you
want to connect the External NiMH Battery (Part No.
571 204 270) to the Geodimeter instrument via a standard
Hirose cable. The adapter slides onto the upper side of the
External Battery. The adapter has two Hirose contacts and a
bracket for attaching it to a tripod.
Multi Adapter
The Multi Adapter (Part No. 571 204 273) is used to
connect up to three External NiMH Battery units (Part No.
571 204 270) to the Geodimeter instrument via a standard
Hirose cable. The adapter slides onto the upper sides of the
External Batteries. The adapter has 2+2 Hirose contacts and
a bracket for attaching it to a tripod. Three External
Batteries will result in a total capacity of 10.5 Ah!
