1.3.4
STATION ESTABLISHMENT CHAPTER 3
GEODIMETER SYSTEM 600
This should be done to get full accuracy of the systems
inherent intelligence.
Comp init
Wait
I 14:04
The instrument is levelled.
Start compensator calibration by
pressing A/M- or ENT-key.
A beep is heard and the display will
change to.....
The instrument automatically turns
200 gon (180
°
) away from you. After a
few seconds a beep is heard and the
instrument turns back and the display
will change to.....
.....program 0. The apperance of P0
indicates that the instrument is
sufficiently well levelled and that the
compensator is now engaged. It also
means that the electronic level is in the
"fine mode" in which each individual
left or right movement of the cursor
represents 20 .
Calibration of the dual-axis compensator with servo
cc
A/M
Note!
☛
Discon-
nect the
compen-
sator by
setting
function
22=0.
P0 14:05
Temp=20.0_
