9.4 Reference Element - Reference Arc

9.4.1 Overview

Description The Reference Element - Arc application allows the user to define a reference

arc and then complete the following tasks with respect to the arc:

• Line & offset

• Set out (Point, Arc, Chord, Angle)

Access 1) Select Apps from the MAIN MENU.

2) Select Reference Element from the APPS menu.

3) Complete application pre-settings. Refer to "8 Applications - Getting

Started".

4) Select Arc.

Next step Define the reference arc.

Default Chapter6
- Table of Contents6
- Table of Contents Zoom10
