Zoom | 232Technical Data
14.6 General Technical Data of the Instrument
Telescope
Compensation Quadruple axis compensation (2-axis compensator with HA-collimation and
VA-Index).
Magnification: 30 x
Free Objective aperture: 40 mm
Focusing: 1.7 m/5.6 ft to infinity
Field of view: 1°30’/1.66 gon.
2.7 m at 100 m
Angular accu-
racy
Setting accuracy Setting range
["] ["] [mgon] [’] [gon]
20.50.2±40.07
310.3±40.07
51.50.5±40.07
720.7±40.07
