Safety Directions Zoom | 211

Labelling

a) Laser beam

Zoom_020

a

Laser Aperture

Laser Radiation

Avoid direct eye exposure

Class 3R Laser Product

according to IEC 60825-1

(2007 - 03)

Po 5.00 mW

λ = 650 - 690 nm
