Technical Data Zoom | 229
Accuracy
Beam interruptions, severe heat shimmer and moving objects within the beam
path can result in deviations of the specified accuracy.
Characteristics
Standard
measuring
ISO 17123-4 Measure time,
typical [s]
Measure time,
maximum [s]
Long range 5 mm + 2 ppm 2.5 12
Principle: Phase measurement
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: System analyser basis 100 MHz - 150 MHz
