Zoom | 34Operation
6 Accept with OK.
4 Center the electronic level of the first
axis by turning the two footscrews.
Arrows show the direction of rotation
required. When the electronic level is
centered the arrows are replaced by
checkmarks.
5 Center the electronic level for the
second axis by turning the last foot-
screw. An arrow shows the direction of
rotation required. When the electronic
level is centered the arrow is replaced by
a checkmark.
)
When the electronic level is
centered and three checkmarks
are shown, the instrument has
been perfectly levelled up.
