Zoom | 74Functions
DIST-OFF
DEFLT
To reset offset values to 0.
Field Description
Trav.
Offset
Perpendicular offset. Positive if the offset point is to the right of
the measured point.
Length
Offset
Longitudinal offset. Positive if the offset point is further away
than the measured point.
Z-Offset Height offset. Positive if the offset point is higher than the meas-
ured point.
Mode Period for which the offset is to apply.
0 after REC The offset values are reset to 0 after the point is
saved.
Contin-
uous
The offset values are applied to all further meas-
urements.
