Page 42 of 127
Operating Manual
OMGEM5KN – Iss. 5.1
Copyright – Geotechnical Instruments (UK) Ltd
Diagnostics
This option enables the Geotech Technical Support Team to identify and resolve issues with the
instrument and settings. If required, the operator may be asked to confirm the diagnostics
displayed.
1) Select the ‘Menu’ key on the front of the analyser to display the ‘Device Settings’ menu.
2) Select ‘Key 4 – Diagnostics’ and the following screen is displayed:
Diagnostics
3) Select soft-key ‘Next’ to display the next screen, ‘Previous’ to return to the previous screen, or select
soft-key ‘Exit’ to exit this screen and return to the ‘Device Settings’ menu.
Note: For further information please contact Technical Support at Geotech on +44(0)1926 338111 or email
technical@geotech.co.uk.
Navigation (optional)
This option enables the operator to switch the ‘GPS Navigation’ functionality on or off. (This is
optional and dependent upon purchasing the navigation option).
1) Select the ‘Menu’ key and the ‘Device Settings’ menu is displayed.
2) Select ‘Key 5 – Navigation On’ to switch on the GPS navigation functionality or ‘Key 5 – Navigation
Off’ to switch the GPS navigation functionality off.
Note: For further information please refer to section ‘8.0 – Taking Readings’.
