Operating Manual
OMGEM5KN Iss. 5.1
Copyright Geotechnical Instruments (UK) Ltd
GEM5000
Horizontal:
Estimate of horizontal error on the indicated position. The
location is accurate to horizontal error 1.6m.
Vertical:
Estimate of vertical error on the indicated position.
HDOP:
‘Horizontal Dilution of Precision’ which measures the accuracy of
the indicated position.
Changing the selected ID
It is possible to change the currently selected ID (identified by green icon ) by pressing the 2 and
8 and keys to move the cursor up and down the list of visible Ids. To change the selection press
Enter. Notice that the selected ID moves to the top of the list and its icon turns green.
Changing the scale
You can change the display’s scale by using the 4 and 6 keys to zoom in and out.
GPS signal strength:
This icon shows the signal strength the analyser’s GPS module is
able to provide. Full, okay and fair strength respectively.
GPS failure - the GPS was unable to get a line of sight lock on
enough satellites. Or, it may be that it hasn’t had time to get a
lock.
7) Select soft-key ‘Continue’ and the operator is returned to the ‘Main Gas Read Screen’.
Taking gas and flow measurement
The top methods of taking a reading
There are two methods to taking a reading, simple gas and a detailed reading, please below for explanations of
both:
Simple gas: Just takes a gas reading and nothing else, this mode can be accessed via the special actions.
Detailed reading: This mode takes you through various steps to achieve (system and barometric) pressure,
gas readings and flow (if required).
Detailed reading explained
With a detailed reading everything is operated of the right soft key, the process will be slightly different
depending on whether you have user prompts enabled but either way it is the same process.
Selecting ID (if required) > Air purge/Baro reading > Relative pressure reading > Gas reading > Flow (if required) >
Answering ID questions (if required) > Store.
A full detailed flow chart of the process can be found on the next page.
