Administrator Mode
113
4 4
Interval: Use the drop-down list to specify how frequent the
images are sent to the FTP server.
Enable Recycling: Select this option to recycle the FTP storage
at the specified Keep Day.
Keep Days: Specify how frequent the images saved at the FTP
server are recycled. By default, the Keep Day is set to 1.
IMPORTANT: To send FTP alerts upon motions, be sure to set up
detection area on the Motion Detection’s page.
[Act as FTP Server] Note this function is not available for Target Series.
Enable FTP access to the GV-IP Cam: The camera acts as an FTP
server, enabling users to download AVI files.
Use alternative port: The default port is set to 21.
To access the internal FTP server through a web browser, enter the IP
address or the domain name of the camera in your browser like this:
ftp://192.168.0.10
When you are prompted for Username and Password, enter the default
value username ftpuser and password 123456. Then you should find the
AVI files recorded after trigger events.
To change login information of the internal FTP server, see 4.9.3 User
Account. For related settings to send FTP alerts, see 4.1.2 Motion
Detection, 4.3.1 Input Settings, and 4.5 Monitoring.
Note: For GV-BX12201, the maximum resolution of the captured still
image sent by FTP alert is 1 MP.
