96
4.2.2.3 Loitering
After movement occurs at a specific area and exceeds the defined time
threshold, the event will be recorded to the connected surveillance system
GV-VMS for later retrieval.
Figure 4-19
1. Select Enable.
2. Select Loitering.
3. To define a detection region:
A. Use the slider to set a desired sensitivity level for the detection
region you want to define in step 4B. The sensitivity levels
range from 1 to 10, with 8 as default. The higher the level, the
more sensitive the camera is to motion.
B. On the live view, draw a detection area. To draw an irregular
shape, drag one or more of the red dots that outline the box
until the line is in the shape that you want. See Figure 4-13.
C. Click Fix to confirm your setting.
