3
Ref
Component Description
Indicators
Power Lights blue when the device is turned on.
Blinks blue when the device is in Suspend mode.
Suspend mode is a deep sleep mode that saves more
battery power. The device automatically enters
Suspend mode after remaining idle in Sleep mode
for some time. The device will wake up upon an
external event (such as a button press or an alarm).
Airplane
mode
Lights blue when the RF (Radio Frequency) radio of
any RF feature (WLAN/Bluetooth/WWAN) is on. If
Airplane mode is switched on, the light turns off.
Battery
Charge
Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green when the battery is being discharged
intentionally due to the battery protection mechanism.
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this
happens.
Speaker Plays music, sounds and voices.
Handle
(optional)
Provides a convenient way to carry the device.
NOTE: When carrying the device around, always use the
handle.
When placing the device on a table top for work,
rotate the handle backwards to serve as a stand.
NOTE: The hardware buttons (except the power button) can be re-defined using
Getac Settings.
