GEZE ECturn Wiring Diagram

ECturn/ECturn Inside
29
Motor
15.2.1 Mains connection for installation in the frame
L
N
BK
BU
1
3
2
4
BK
BU
L
N
+
DCU703
N
–
+
T
2
1
3
4
5
–
110 V–230 V AC
1 Mains fuse provided on site
2 Main switch (optional)
3 Power supply
4 Ferrite sleeve
5 ECturn Inside drive
15.2.2 Mains connection for installation in the leaf
Drip loop, mat. no. 106131
L
N
BK
BU
1
3
2
4
BK
BU
L
N
+
–
–
–
+
+
-
+
NT
+
2
1
3
4
5
6
DCU703
110 V–230 V AC
1 Mains fuse provided on site
2 Main switch (optional)
3 Power supply
4 Drip loop
5 Ferrite sleeve
6 ECturn Inside drive
16 Motor
à Motor gear unit for ECturn, mat. no. 131471
à Motor gear unit for ECturn Inside, mat. no. 149501
3
A
MOTOR
M
+
-
MOT_A
MOT_B
MOTOR
IGM
BU
YE
GN
BN
1
GND
2
B
4
5V
IGM
RD
BK
