Commissioning and service
X
Actuate drive (K, KB or radio remote control).
The door opens slowly to the open position. Afterwards the door then closes again with slower speed.
Flashing of the mode of operation LED stops as soon as the drive was able to move through the taught opening
angle range.
X
Terminating commissioning:
à Check function and detection areas of all contact sensors.
à Check function and detection areas of the safety sensors for monitoring opening and closing. Check sensor
strips of each individual sensor module.
20.5 Commissioning the drive with GC 338
X
If necessary, insert DPS into the control unit.
X
If necessary, connect the rechargeable battery to the control unit.
X
Switch on the on-site power supply of the drive.
à Display:
à The mode of operation display on the drive lights up yellow (parameters to factory settings).
à DPS:
le
(learn)
X
Set the parameters, in particular (if necessary or required):
à
TO
(electric strike) to the type of electric strike used
à
e1
/
e2
(congurable input) t the required function
à
a1
(congurable output) to the required function
à
ac
(power failure) to the required function
à
aT
(drive type) to the version of the drive
X
Deactivate safety sensors by parameter adjustment on the control unit:
à
s1
(safety closing) to
00
, for “no SIS” (factory setting)
à
s3
(safety opening) to
00
, for “no SIO” (factory setting)
à
Te
(testing) to
00
, for “no testing” (factory setting)
X
Start learning:
à With S1, S2: Request service menu by pressing buttons S1 and S2 at the same time.
à Actuate S1 briey to get to parameter
le
(learning).
à Press S1 for 2 s to start the learning mode.
à With DPS: select
le
for learning.
à Press the  key.
à Display DPS:
l1
à A conrmation signal will sound. Display service LEDs:
5
○
4
○
3
○
2
○
1
●
With ECturn Inside:
X
Remove DPS.
X
Move the door leaf by hand to the desired open position.
X
Move the door leaf by hand completely to the closing position.
With ECturn Inside:
X
Move the door leaf as far out of the closing position as necessary to make buttons S1 and S2 or the DPS connection
easily accessible again.
X
End learning.
à With S1, S2: Press button S1 for 2 s.
à With DPS:
With ECturn Inside:
X
Plug DPS in.
X
Press the  key.
A conrmation signal will sound. The opening angle of the door is now known to the control unit.
The mode of operation LED is o.
With ECturn Inside:
X
Before leaving the service menu, block the door leaf mechanically if parameter
of
(retaining action) or
cf
(retaining action closing) are not set to
00
(factory setting).
Otherwise the door leaf can move in closing or opening direction and the control unit can become damaged.
