GEZE ECturn Wiring Diagram

ECturn/ECturn Inside
7
Electrical data
3 Electrical data
ECturn ECturn Inside
Mains voltage 110 V to 230 V ±10% 110 V to 230 V ±10%
Frequency 50 Hz to 60 Hz 50 Hz to 60 Hz
Protection rating I II
Capacity rating 75 W 92 W
Mains connection Safety plug (plug type F, CEE7/4)
or
Fixed connection (installation cable
or drip loop)
Fixed connection (installation cable
or drip loop)
Primary fuse 4 AT, 5×20 mm –
Secondary fuse (self-resetting) 0.75 AT, 5×20 mm 0.75 AT, 5×20 mm
Secondary voltage power supply 24 V DC 24 V DC
Control voltage for external
components
24 V DC ±10% 24 V DC ±10%
max. output current
Control voltage 24 V
600 mA 600 mA
Rechargeable battery NiMH, 19.2V, 650 mAh NiMH, 19.2V, 650 mAh
Temperature range –15 … +50 °C –15 … +50 °C
IP rating IP20 IP20
