ECturn/ECturn Inside
38
Parameter menu
21 Parameter menu
DPS Service LEDs Parameter Encoding Explanation
5 4 3 2 1
Uo
*
○ ○ ○ ●
Opening speed 9, 18, ..., 90 °/s
Uc
*
○ ○ ● ○
Closing speed 9, 18, ..., 90 °/s
sc
*
○ ○ ● ●
Latching action closing position 00
09 ... 45
no latching action
°/s
Speed at which the drive moves to the closing
position shortly before closing.
Oh
*
○ ● ○ ○
Hold-open time 00 ... 05 ...
10, 12 … 20,
25, 30
s
Os
*
○ ● ○ ●
Hold-open time KB 00 ... 05 ...
10, 12 … 20,
25, 30
s
TO
*
○ ● ● ○
Electric strike 00 no electric strike
01 Fail-secure electric strike
02 Fail-safe electric strike
03 Motor lock
04 Fail-secure electric strike with close pressure
before opening
05 Fail-safe electric strike with close pressure before
opening
06 Motor lock with close pressure before opening
aI
*
○ ● ● ●
Opening delay 00 ... 90 × 0.1s
for K and KB
pU
*
● ○ ○ ○
Push And Go 00
01 ...18 20
no Push And Go
Push And Go, activating angle 1°-18°, 20°
pC
*
● ○ ○ ●
Push To Close 00 no Push To Close
01 Push To Close in AU, NA
02 Push To Close in DO, drive changes to AU.
03 Push To Close in AU, NA, DO. With Push To Close
in DO, the drive changes to AU.
e1
e2
*
● ○ ● ○
ECturn: congurable input 1
ECturn Inside: congurable
input 2
00 no function
01 Sabotage
02 Switch function
03 Switch function close after hold-open time
04 NA mode of operation
05 Stop
06 Bolt message normally open contact
07 Bolt message normally closed contact
08 Contact sensor K
09 Mechanical programme switch MPS (ECturn
Inside only)
11 Contact sensor K / DO mode of operation
21 WC control
a1
*
● ○ ● ●
programmable output 1 00 no function
01 Gong (with contact sensor K activated)
02 Fault
03 Electric strike
04 closed and locked
05 closed
06 opened
07 OFF
08 NA
09 AU
