GEZE ECturn Wiring Diagram

ECturn/ECturn Inside
39
Parameter menu
DPS Service LEDs Parameter Encoding Explanation
5 4 3 2 1
10 DO
12 AU or DO
13 WC control
B1
*
● ● ○ ○
Gong signal 00
01
02
o
quiet
loud
Gong signal when the contact
sensor K is activated
B2
*
● ● ○ ●
Movement signal 00
01
02
o
Quiet
loud
Alarm signal during the open-
ing and closing movement
s1
*
● ● ● ○
Security close 00
01
02
no SIS
SIS
SIS and K
Safety function
Safety function SIS and activa-
tion function K
s3
*
● ● ● ●
Security open 00
01
no SIO
SIO
Safety function
Te
**
○ ○ ○ ●
Testing 00 no testing
01 Testing with 24 V
02 Testing with GND
ac
**
○ ○ ● ○
Power failure in AU or DO
00 no function
01 open and switch o
02 close and switch o
03 Rechargeable battery operation 15 min
Bo
**
○ ○ ● ●
Accelerate opening 05 ... 20 ... 90
Bc
**
○ ● ○ ○
Acceleration closing 05 ... 20 ... 90
fo
**
○ ● ○ ●
max. torque opening 01 ... 04 ... 09 × 10Nm
fc
**
○ ● ● ○
max. torque closing 01 ... 04 ... 09 × 10Nm
of
**
○ ● ● ●
Retaining action opening 00 ... 11 Nm
cf
**
● ○ ○ ○
Retaining action closing 00 ... 11 Nm
fs
**
● ○ ○ ●
Closing position torque 00 No closing position torque
10 … 40 Torque acts after the end of the latching action
in the closed position. Manual opening is more
dicult while the torque is eective. The higher
the set torque, the longer this lasts. Examples:
à at 10Nm = 0.5s,
à at 40Nm = 2s.
aT
**
● ○ ● ○
Drive type 01 1-leaf single-action door with guide rail,
low-energy mode
02 1-leaf single-action door with link arm,
low-energy mode (ECturn only)
03 1-leaf single-action door with guide rail,
automatic mode
04 1-leaf single-action door with link arm, automatic
mode (ECturn only)
cp
**
● ○ ● ●
Factory setting 00 Parameters are not reset
01 Parameters are reset
ep
**
● ● ○ ○
Software version 01 05 00 e.g. for V1.5
sa
**
● ● ○ ●
Service display Co xx xx xx
Ho xx xx xx
When paging using the arrow keys the values
with the following meaning are displayed:
Co Number of cycles
Co 00 34 00 means 3400 cycles
Ho Operating hours
Ho 00 12 00 means 1200 hours
e®
**
● ● ● ○
Currently queued errors CE Clear error memory
