ECturn/ECturn Inside
30
Rechargeable battery
17 Rechargeable battery
à Rechargeable battery ECturn, mat. no. 131473
à Rechargeable battery ECturn Inside, mat. no. 149496
à The rechargeable battery is not in the drive when the unit is delivered.
à The rechargeable battery can be discharged in the delivery state. Therefore the drive has to be operated using
the on-site power supply for at least 24 hours after connection of the rechargeable battery in order for the
rechargeable battery to charge.
à Rechargeable battery voltage in charged state: ≥ 21.6 V (with rechargeable battery unplugged)
à The rechargeable battery has to be replaced every 2-3 years.
X
Set parameter
ac
for the required behaviour of the drive in the event of an on-site mains voltage failure
(see chapter 21, “Parameter menu”):
à After a supply voltage failure the drive still carries out the function set with parameter
ac
. Then the drive
switches itself o by disconnecting the connection to the rechargeable battery.
If the NA, AU or DO mode of operation is set, the drive can be activated via the KB input or one f the radio
channels FK1 or FK2. With
ac
=
01
the drive opens and switches o in the open position. With
ac
=
02
the
drive opens and closes and switches o in the closing position.
BK
AKKU
-
+
-
RD
19,2 V
