5 Starting up the control

▶ Supply cables

Insert / switch on

DES: Rapid adjustment of final limit positions

1. Check output rotating direction

2. Move to OPEN final limit position 3. Save OPEN final limit position

4. Move to CLOSE final limit position 5. Save CLOSE final limit position

Note!

 The rapid adjustment is complete, "Hold-to-run" door operating mode is active

 Change of OPEN/CLOSE final limit positions via menu items "1.1" to "1.4"

 Pre-limit switch Safety edge is set automatically

 Changing the pre-limit position is possible via menu item "1.5"
