42
X7: Input pull switch/radio receiver
Connection of a pull switch or external radio receiver via the terminals X7/1 and X7/2. The
switching contact must be potential-free (NO contact).
Pull switch or radio receiver function
Menu item "2.6":
Pulse type Reaction upon activation
„.1“
Door is in OPEN final limit position or respectively in intermediate open
position: The door CLOSES
From all other door positions or door movements: The door OPENS
„.2“ OPEN-STOP-CLOSE-STOP-OPEN command order
„.3“ Door always executes OPEN movement
