41
Disconnection of photo cell function (only DES)
Menu item "3.2"
Function Disconnection of photo cell function
„.0“ Off
„.1“ On
The teach-in mode gets activated after exiting the programming.
Warning!
Presence detection is disabled in the teach-in mode
In the teach-in mode, the door must be fully opened and closed twice. The light beam must
be interrupted twice at the same door position. The teach-in mode is then terminated. The
photo cell has no function below this stored door position.
Teach-in mode display
Upon exiting the program
When the light beam is interrupted for the first time
After the second interruption to the light beam at the same door position, and with
the CLOSE final limit position reached
Note!
If the teaching-in is not successful, open and close the door again, so that two
identical door positions are stored
