38
X4: Input, automatic closing Off/On
Connection of a switch via the terminals X4/1 and X4/2 for switching the automatic closing off
and on.
X5: Input, control device
Warning!
▶ "Hold-to-run" door operating mode:
The door must be fully visible from the operating point
The door operating mode "3" allows a place of installation of the control device without sight
of the door.
Note!
▶ Application without STOP push-button: Connect wire link X5.1 to wire link X5.2
If the safety edge or photo cell fails, the control device will not function
