X8: Input, intermediate stop On/Off
Connect a switch to terminals X8/1 and X8/2 to activate and deactivate the intermediate
open. The intermediate open position muss be programmed via menu item “1.6”.
With an OPEN command, the door moves to the stored door position. When the Intermediate
open function is deactivated, the door can move back to the OPEN final limit position.
intermediate open function
Menu item "2.9":
Function Intermediate open
„.1“  All command inputs
„.2“
 Intermediate open via X7 pull switch
 OPEN final limit position via all other control devices
„.3“
 Intermediate open via external control devices X5 and OPEN push button
of the control
 OPEN final limit position via all other control devices
Note!
 Double command with functions „.2" and „.3": Priority is given to OPEN final limit
position, independent of command sequence
