GFA TS 970 - Electrical Installation - Accessory Connections; Light Curtain, Receiver, and Pull Switch Connections

18
Light cur tai n X 6
Light curtain X6
X20
20.1 20.2 20.3
24V
24V*
X6
12
24V
A25
1234
5
24V
A26
24V
24V*
PNP
X6
12
24V
A27
12 3
24V
A28
24V
24V*
X20 Function relay Light curtain Light curtain
Test light curtain A25 Transmitter A27 Transmitter
A26 Receiver A28 Receiver
Radi o r eceiv er X7
Pull switch X7
Interme diate o pen X8
Radio receiver X7 Pull switch X7 Intermediate open X8
1234
24V
X7
A13
A14
4
3
X7
S19
A15
12
4
3
S17
X8
Traffic li ght X20
Magnetic brake X20
Traffic light X20 Magnetic brake X20
20.1 20.2 20.3
H1
1.9 1.8
X20
20.1 20.2 20.3 1.9 1.8
Y1
G1
C1
H1 Traffic-light G1 Rectifier
Y1 Magnetic brake
