37
10 Functional description
X: 24 VDC voltage supply
Connection of external devices such as photo cell, radio receiver, relay, etc. via the "24 V"
and "GND" terminals.
Attention – Damage to components!
Total current consumption of external devices: maximum 180 mA
X1: Mains supply of the control and supply of external devices
Mains supply of the control
Connection via the terminals X1/1.1 to X1/1.4 and PE.
Various mains connections: 3 N~, 3~, 1 N~ for symmetric and asymmetric motors.
Power supply 400 V = Wire link 1.5 – 1.6
Power supply 230 V = Wire link 1.6 – 1.7
Note!
▶ Pay attention to the "Mains supply connection" and "Mains supply connection to
control" descriptions
Supply of external devices
Connection of external devices for 230 V, such as photo cell, radio receiver, relay, etc. via
terminals X1/1.8 and X1/1.9.
Note!
Mains supply: 3 N~400 V or 1 N~230 V, symmetric
Protection via F1, 1.6-A time-lag micro-fuse
