GFA TS 970 - 2 Technical Data

7
2 Technical data
Series TS 970
Dimensions W x H x D 155 x 386 x 90 mm
Installation Vertical, free of vibration
Operating frequency 50 / 60 Hz
Supply voltage (+/- 10%)
1 N~230 V, PE
3 N~230 / 400 V, PE
3~230 / 400 V, PE
Output power for drive unit, maximum 3 kW
Protection per phase, on-site 10-16 A
External mains supply:
(internal electronic protection)
24 V DC
0.18 A
External mains supply: X1/L, X1/N
(protection via F1 micro-fuse)
1 N~230 V
1.6 A time-lag
Control inputs
24 V DC
Type 10 mA
Relay contacts
1 potential-free
changeover contact
Load of the relay contact
ohmic/inductive
230 V AC, 1 A
24 V DC, 0,4 A
Control power consumption 11 W
Temperature range
Operation: -10..+50
Storage: +0..+50
°C
Air humidity
up to 93 %
non-condensing
Protection class of housing IP54
Compatible GfA limit switch
NES (mechanical limit switch)
DES (digital limit switch)
