GFA TS 970 - Page 56

56
Symbol Explanation
Prompt: Setting via OPEN/CLOSE built in push-button;
Use OPEN push-button to increase value, CLOSE push-button to decrease value
Prompt: Press stop button once via built in push-button
Prompt: Save,
press stop button once via built in push-button
Prompt: Save,
press stop button for three seconds via built in push-button
Prompt: Reset the control,
press stop button for three seconds via built in push-button
Prompt: Move to door position
Prompt: Move to door position for OPEN final limit position
Prompt: Move to pre-limit
Prompt: Move to door position for CLOSE final limit position
